Modular Cleanroom panel - uPVC coated metal walls

December 16, 2021

Galvanized uPVC coated steel panel 0.7-0.8 mm thick.
Panel is coated with 100µ PVC.

Technical specification

Modular Cleanroom panel - uPVC coated metal walls

  • Cleanroom panel with High mechanical resistance due to high thickness and PVC coating
  • 45mm- 82mm with return air incorporated in the cleanroom panel
  • Resistant to low humidity and to High RH humidity variations
  • Aluminum honeycomb panel insulation
  • Hi density Rockwool panel insulation( flame resistant polyurethane insulation available. )
  • Non silicone caulking and cold welds systems on PVC panel are available for both uPVC panel and powder coated wall panels
  • The Sandwich panel is Resistant to very aggressive cleaning and sanitizing agent. Easy cleaning
  • Hygienic wall cladding.
  • uPVC wall panel FM and ASTM e 84 certified.

50mm Clean Room Wall Panels –50mm aluminum honeycomb panels are FM approved and the most popular within the range, providing a high specification option with an outstanding strength to weight ratio.

10mm Aluminum Honeycomb Lining Panels –  10mm aluminum honeycomb panels have been specifically designed to be used as cladding to existing walls/columns. These FM approved panels can simply be bonded to an existing structure allowing for an exceptionally easy and clean application. Hygienic wall cladding.

17.5mm Lining Panels –  17.5mm aluminum honeycomb lining panel is an effective single wall option for any class of cleanrooms and is perfect for lining existing block walls or studwork as well as upgrading existing facilities.

50mm Ceiling Panels – The 50mm ceiling panel is ideal to create a completely flush ceiling system.

65mm Aluminum Honeycomb Ceiling Panels – 65mm aluminum honeycomb ceiling panels have just recently been developed for a walk on ceiling deck which can take loads up to 3kn per m2 with 2.5m spans.

Turned Box Panel – The turned box panel is used to form air return units & column encasements.

Pre-Formed Corner – The pre-formed corner works in conjunction with all varieties of our 50mm cleanroom panels, providing a 90 degree angle for the corner of cleanroom
